Installation and operating manual50 016-059
4.7 Fitting the cover plate
Grease the seal if required. ➊
If necessary, insert the key and unlock the Lock & Lift system by turning
counter-clockwise.
Fit the cover plate as shown. ➋
Lock the cover plate by turning the key clockwise. ➌
✓ The cover plate is installed.
1
3
2
Fig. [17]
