13. Printing Output to a Printer (Option)
The FD-720 may be connected to a printer to make it possible to output measurement data or
other information to the printer. Output which may be generated includes data consisting of inter-
mediate or final measurements, sample codes, and measurement times.
*A dot-matrix printer may also be used, although it is impossible to obtain graphical output when using a
dot-matrix printer. Please inquire with Kett if you require further information.
13-1 Sample Printer Output
 Output consisting solely of final values from multiple measurements
[Tabular output (TBL)]
[Graph output (GRP)]
Supplier : KETT ELECTRIC LABORATORY
Model : FD-720
Serial number : AC00001
Device ID : ABCD-123
Time of measurement : 2003/08/08
Measuring conditions storage area : 0
Measurement standard : Wet base
Measurement mode : Automatic halting mode
Drying temperature : 110°C
Automatic halting conditions : 0.05%
Bias : 0.00%
Sample code
Time of measurement
Pre-drying weight (g)
Post-drying weight (g)
Measured value (%)
Signature
* Pressing the
key after the
completion of measurement cause the
signature field to be printed.
Supplier : KETT ELECTRIC LABORATORY
Model : FD-720
Serial number : AC00001
Device ID : ABCD-123
Time of measurement : 2003/08/08
Measuring conditions storage area : 0
Measurement standard : Dry base
Measurement mode : Timed halting mode
Drying temperature : 110°C
Measurement time : 10 mins.
Bias : 0.00%
Sample code
Time of measurement
Measurement graph
