Description
3.4 Brake system
The bicycle is equipped with a disc brake.
1
2
3
4
5
Figure 5: Rim brake components with details – example: Magura HS22
1 Rear wheel rim brake
2 Brake booster
3 Brake lining
4 Handlebars with brake levers
5 Front wheel rim brake
The rim brake stops the wheel moving when the rider
pulls the brake lever, causing two brake linings,
positioned opposite one another, to be pressed onto
the rims.
