Description
3.6.2 Operating element with display
The operating element with display controls the drive
system and shows journey data.
The bicycle's battery supplies the operating element
with display with energy when a sufficiently charged
battery is inserted on the bicycle, and the drive system
is switched on.
Table 10: Display technical data
Storage temperature 5 °C–25 °C
Charging ambient temperature 10 °C–30 °C
The operating element with display has three buttons
and three indicators.
1
2
3
4
5
6
Figure 10: Operating element overview
Table 11: Overview of operating element with indicators
1 On-Off button
2 Charge status indicator
3 Level of assistance indicator
4 Speed or system message display
5 Down button
6 Up button
