Kewtech KT35 User Manual

6
4 Specifications
Insulation Resistance Measurement Specification
Test Voltage 250V 500V 1000V
0 -20M Ω 0 -20M Ω 0 -20MΩ
Measuring Ranges 0 -200M Ω 0 -200M Ω 0 -200MΩ
0 -2000M Ω 0 -2000M Ω 0 -2000MΩ
Nominal Output 250V DC min. 500V DC min. 1000V DC min.
Voltage (UN) at 0.25MΩ at 0.5MΩ at 1MΩ
Nominal Output 1mA DC min. 1mA DC min. 1mA DC min.
Current (In) at 0.25MΩ at 0.5MΩ at 1MΩ
±(5% rdg + 5 dgt)
Intrinsic
Accuracy
Continuity Resistance Measurement Specification
Measuring Ranges 0 -20Ω 0 -200Ω 0 - 2000Ω
Open circuit voltage (Uq)
4 - 9V
on the 20Ω range
Nominal output current (In)
200 mA
on the 20Ω range
Intrinsic accuracy 0 -20Ω 0 -200Ω+0 - 2000Ω
Reference Conditions
Ambient Temperature: 23 ± 5°C
Relative Humidity: 60 ± 15%
Supply Voltage: 9 V
Altitude: Less than 2000m
20MΩ
200Mz
2000MΩ
0 to 1GΩ
1G to 2Gz
±(10% rdg + 3 dgt)
±(3% rdg + 3 dgt)
±(1.5% rdg+ 5dgt)
±(1.5% rdg+ 3dgt)
