Key Automation SOLE User Manual

15
EN
2.1 - Product description
2 - PRODUCT OVERVIEW
2.2 - Models
2.3 - Technical characteristics
Solar powered kit for the automation of gates and barrier gates (g.1).
PF30W
MODEL DESCRIPTION QUANTITY
PF30W 30W solar panel 1
SOLE
MODEL DESCRIPTION QUANTITY
Box Box with control card with two batteries 1
Batteries 12V - 18Ah - AGM batteries 2
Panel Mount Bracket Flat mount bracket 1
Bag with screws xing hardware for solar panel 1
SOLEAU
MODEL DESCRIPTION QUANTITY
Box Box with control card without batteries 1
Panel Mount Bracket Flat mount bracket 1
Bag with screws xing hardware for solar panel 1
BATTERIES
MODEL VOLTAGE
OF FLOAT
CHARGING
VOLTAGE OF
ABSORPTION
CHARGING
TIME OF
ABSORPTION
CHARGING
VOLTAGE OF
EQUALIZED
CHARGING
TIME OF
EQUALIZED
CHARGING
INTERVAL OF
EQUALIZED
CHARGING
GEL 27.6V 28.4V 2h -- -- --
Sealed 27.6V 28.8V 2h 29.2V 2h 28 day
Flooded 27.6V 29.2V 2h 29.6V 2h 28 day
User 27.6V 28.8V 2h 29.2V 2h 28 day
We strongly suggest to use 2× GEL batteries 12V, 18Ah, AGM (absorbent glass mat) type.
SOLAR CHARGE CONTROLLER
INPUT VALUE
PV voltage < 50V
Rated current 20A
OUTPUT
VALUE
System voltage 24V
HVD 32V
Rated discharge current 20A
No-load loss < 13mA
Charge loop voltage drop < 0.21V
Discharge loop voltage drop < 0.12V
Charging mode PWM Multi-stage (bulk, absorption, oat, equalized)
Voltage of oat charging 27.6V (26V ~ 30V)
Voltage of absorption charging 28.8V (26V ~ 30V)
Duration of absorption charging 16 h with solar panel / 2 h with rated current
Voltage of equalized charging 29.2V (26V ~ 31V)
Duration of equalized charging 16 h
LVD 21.6V (20V ~ 28V)
LVR 25.2V (20V ~ 28V)
Load working mode (see par. 5.6) DEFAULT
NIGHT 1
NIGHT 2
Light control voltage 10V (2V ~ 20V)
Battery type GEL, SLD, FLD and USr
USB 5V 1A
Man-machine interface LCD, 2 buttons
Wiring PCB terminal, <6mm
2
Working temperature -20 ~ +50 °C
Storage temperature -30 ~ +60 °C
Working humidity 10% ~ 90%, no condensation
Plastic box dimension (mm) 316 (L) × 396 (A) × 188 (P)
Weight (box without batteries) 3 kg (Add 25kg for the approx batteries weight)
IP Code 56
