TCP/IP and RS-232 Commands
• KD-PS42 allows control over serial interface for bi-directional
communication.
• Use Unit Control pins 4, 5, and 6 for RS-232 communication
• Serial interface may also be accessed using a TCP/IP connection or using
the USB Service port
• Default IP address is 192.168.1.239, with default port 23
Connection Protocol
• Baud Rate = 57,600 bits per second as default
o Note: Activating KD-CamUSB or KD-Amp220 control mode will automatically adjust the baud-
rate to 9,600. It must be 9,600 to support KD-CamUSB and KD-Amp220 Integrated Systems
• Data Bits = 8
• Stop Bits = 1
• Parity = None
• Flow Control = None
• Carriage Return = Required at end of each string
Notes:
• Commands are not case-sensitive
• Spaces are shown for clarity; commands should NOT have any spaces
• After a new command is received, a prompt should be sent back
