KEY RAY - Table of Contents

TABLE OF CONTENTS
WHAT’S IN THE BOX
GATE ARM
Product Overview........................................................1
Preliminary Checks.......................................................1
Quick Start Installation.....................................................2
Installation Guideline......................................................4
Testing and Commissioning the Automation....................................8
Safety Warnings.........................................................9
Instructions and Warnings for the End User....................................10
CONTROLLER
About the Controller......................................................12
Technical Specifications..................................................13
Preliminary Checks................................... ...................13
Installing the Controller...................................................14
Quick Programmming Guide...............................................16
Full Programmming Guide.................................................19
Testing and Commissioning the Automation..................................25
Further Details..........................................................26
Controller Safety Warnings................................................30
Instructions and Warnings for the End User....................................31
Before proceeding with the installation, check the integrity of the product and that all the components are present in
the package.
(1) ECLIPSE
LIGHT
RAY GATE OPERATOR
(1) for SINGLE SWING GATE OR
(2) for DOUBLE SWING GATE
(1) RX4X
RECEIVER
(2) CHAMELEON
TRANSMITTERS
(1) 14A
CONTROLLER
(1) STICKER WITH
WARNING TAG
(1) FRONT MOUNTING
BRACKET
(1) REAR MOUNTING
BRACKET
(1) FT32 PHOTOCELL
