PRODUCT OVERVIEW
Description of the product
The RAY gear motors are destined to be installed in systems for the
automation of gates with hinged doors.
The RAY gear motors have been designed and constructed to be
The use of gear motors for applications which differ from those
indicated above is prohibited.
Model and technical characteristics
PRELIMINARY CHECKS
Before installing this product, verify and check the following steps:
- Check that the gate or door are suitable for automation
- The weight and size of the gate or door must be within the maxi-
- Check the presence and strength of the security mechanical stops
of the gate or door
- Check that the mounting area of
-
ing
- Conditions of high acidity or salinity or proximity to heat sources
could cause malfunction of the product
- Extreme weather conditions (for example the presence of snow,
ice, high temperature range, high temperatures) may increase the
friction and therefore the force required for the handling and initial
starting point may be higher than under normal conditions.
- Check that the manual operation of gate or door is smooth and
friction-free and there is no risk of derailment of the same
- Check that the gate or door are in equilibrium and stationary if left
in any position
- Check that the power line to supply the product is equipped with
proper grounding safety and protected by a magnetothermal and
differential security device
- Provide the power system with a disconnecting device with a gap
of contacts enabling full disconnection under the conditions dictated
by the overvoltage category III.
- Ensure that all materials used for the installation comply with cur-
rent regulations
RAY4024E: Gear motor for hinged gate with max length of 13 feet and 500 lbs or 6 1/2 feet and 1320 lbs.
(Refer to chart in Fig 2 for limit use.)
TECHNICAL SPECIFICATIONS
RAY4024E
Thrust force 2000 N
Working cycle 80%
Opening time at 90° (sec) 20-25*
Working stroke 415 mm
Control board 14AB2
Secondary Power 24 Vdc
Primary Power 110 Vac
Absorption 5 A
Engine power 120 W
Integrated lights yes
Degree of protection NEMA 3R (IP44)
Dimensions (L - P - H) 33 7/32” x 3 15/16” x 4 3/32”
Weight 18 lbs
Operating temperature -4°to 133°F
Leaves maximum weight 1320 lbs
1
