KEY RAY - Page 5

USE LIMITATIONS
SPACE DIMENSIONS
LBS
Maximum weight of the gate
FT
Maximum length of the gate
OPTIMAL INSTALLATION
MAX GATE WEIGHT (lbs)
MAXIMUM GATE LENGTH (ft)
LIMIT USE
1311.51086.5
1320
1100
880
660
440
220
OUTSIDE
PROPERTY
INSIDE
PROPERTY
GATE
Steel Square
Tubing
Fig. 1
Fig. 2
Fig. 3
Gate Closed
Gate Rotation Center (Hinge)
6¾”
6¾”
29½”
Ensure that the gate weight and length is compatible with
the table in Fig 2.
Ensure that the mounting area of the gear motor is compatible with the dimensions in Fig 1.
3
”
15
16
4
”
3
32
33
”
7
32
16
”
11
32
3
