Page #110 background image
Keyscan Inc. Technical Guide (PC109x - 07.15)
110
Repeat connections and jumper settings for each control board and CIM.
Apply power to all CIM and ACU circuit boards.
Do one of the following procedures at the control board:
If this is an existing system, press reset S1 on the control board for board initialization.
If this is a new installation, press S1, wait 5 seconds, and then press S3 within ten seconds. Allow two
minutes for board initialization after clearing memory.
Return to a PC with the Client module, log on to the appropriate site, and perform a full upload.
CIM Connection Diagrams
Observe the diagrams on the following pages for connecting the CIM units to the access control boards and
connecting the CIMs with CAN Bus 1 and CAN Bus 2.
The CIM designated as CIM 0 supports serial or network (TCP/IP) to CANBUS 1 communication. The CIM unit
does not support modem communication.
Note
The control board’s H2 terminal is an open terminal block and does not require setting S2 switches 7 & 8 for
activation.
