134 Keysight FieldFox Handheld Analyzers Service Guide
Repair and Replacement Procedures
Removing and Replacing the Front Panel Group Assemblies
7-
Replacing the A3 Front Panel Interface Board (FPIB)
IMPORTANT The A3 front panel interface board contains a Lithium-ion battery. Refer to
“Battery Disposal” on page 15 for important instructions on disposing of this
printed circuit board with the battery attached. If necessary, the battery can
be removed from the printed circuit board and disposed of separately.
1. Perform the steps under “Pre-replacement Procedure” on page 130.
2. Refer to Figure 7-20. Remove the four screws (2) that secure the LCD
shield and remove the LCD shield. Discard the four screws, new ones are
provided in the Repair and Re-assembly Kit. Be careful. The A2 LCD
display is now loose and will fall out of the front case if the case is tipped.
3. Disconnect the RPG cable, W12, at the A3 FPIB connector as indicated.
4. Disconnect the A2 LCD to FPIB cable, W13, at the A3 FPIB connector as
indicated.
5. Remove the nine screws (3) that secure the A3 FPIB to the front case.
6. Push the nine rubber “nubs” through the A3 FPIB to release the A1 keypad.
The A1 keypad is permanently attached to the front case and must remain.
7. Position the new A3 FPIB in the front case over the A1 keypad and, using
needle-nose pliers, pull the nine rubber “nubs” on the A1 keypad through
the holes in the A3 FPIB. Make sure that all nine of the rubber “nubs” are
fully extended on the back side of the A3 FPIB.
8. Secure the A3 FPIB to the front case with nine new screws (3) provided in
the Repair and Re-assembly Kit.
9. Re-connect theA2 LCD to FPIB cable, W13, to the A3 FPIB connector as
indicated. Route the cable as shown.
10.Re-connect the RPG cable, W12, to the A3 FPIB connector as indicated,
with the A2 LCD to A3 FPIB cable, W13, passing beneath it as shown.
Bend the RPG cable toward the right side as shown.
11.Place the LCD shield back in position on the A2 LCD. Make sure that the
A2 LCD to A3 FPIB cable, W13, is routed between, not under, the shield
gaskets.
12.Secure the shield with four new screws (2) provided in the Repair and
Re-assembly Kit.
13.Perform the steps under “Final Assembly Procedure” on page 164.
