Keysight Infiniium MXR-Series Real-Time Oscilloscopes User's Guide 3
Infiniium MXR-Series Real-Time Oscilloscopes—At a Glance
In addition to the number of input channels, bandwidths, and sampling rates
described in the previous table, the Keysight Infiniium MXR-Series real-time
oscilloscopes deliver these features:
• 10-bit analog-to-digital converter (ADC) with low noise and high effective
number of bits (ENOB), with additional high-resolution settings that increase
the effective number of bits at lower bandwidths.
• Hardware acceleration and high waveform update rates that make it more likely
to capture waveform anomalies.
Table 1 Infiniium MXR-Series real-time oscilloscopes
8-Channel Model 4-Channel Model Bandwidth Sampling rate
MXR608A MXR604A 6 GHz 16 GSa/s
MXR408A MXR404A 4 GHz 16 GSa/s
MXR258A MXR254A 2.5 GHz 16 GSa/s
MXR208A MXR204A 2 GHz 16 GSa/s
MXR108A MXR104A 1 GHz 16 GSa/s
MXR058A MXR054A 500 MHz 16 GSa/s
