Keysight Technologies Infiniium MXR254A

Testing Performance 6
Keysight Infiniium MXR-Series Real-Time Oscilloscopes User's Guide 89
Performance Test Record
Model Number: Tested by:
Serial Number: Work Order No.:
Recommended Test Interval—1 Year/2000 hours Date:
Recommended next test date: Ambient temperature:
Table 5 Input Impedance Test, Channels 1 through 4
Input
Resistance
Vertical
Scale
Channel 1 Channel 2 Channel 3 Channel 4 Limits
50 Ω 5mV/div 48.25Ω to 51.75 Ω
50 Ω 10 mV/div 48.25 Ω to 51.75 Ω
50 Ω 20 mV/div 48.25 Ω to 51.75 Ω
50 Ω 50 mV/div 48.25 Ω to 51.75 Ω
50 Ω 100 mV/div 48.25 Ω to 51.75 Ω
50 Ω 200 mV/div 48.25 Ω to 51.75 Ω
50 Ω 500 mV/div 48.25 Ω to 51.75 Ω
50 Ω 1 V/div 48.25 Ω to 51.75 Ω
1MΩ 5mV/div 990kΩ to 1.010 MΩ
1MΩ 10 mV/div 990 kΩ to 1.010 MΩ
1MΩ 20 mV/div 990 kΩ to 1.010 MΩ
1MΩ 50 mV/div 990 kΩ to 1.010 MΩ
1MΩ 100 mV/div 990 kΩ to 1.010 MΩ
1MΩ 200 mV/div 990 kΩ to 1.010 MΩ
1MΩ 500 mV/div 990 kΩ to 1.010 MΩ
1MΩ 1V/div 990kΩ to 1.010 MΩ
1MΩ 2V/div 990kΩ
to 1.010 MΩ
1MΩ 5V/div 990kΩ to 1.010 MΩ
