12 Keysight PXI/AXIe Chassis Reference Guide
Understand the system hardware connections
Figure 7 M9502A AXIe Backplane Connector Layout
Figure 8 M9505A AXIe Backplane Connector Layout
Zone 2 Zone 1
Instrument Slot 2
Logical Slot 3
Instrument Slot 1
Logical Slot 2
ESM Slot
Logical Slot 1
Zone 2 Zone 1
Instrument Slot 5
Logical Slot 6
Instrument Slot 4
Logical Slot 5
Instrument Slot 3
Logical Slot 4
Instrument Slot 2
Logical Slot 3
Instrument Slot 1
Logical Slot 2
ESM Slot
Logical Slot 1
