Keysight CXG, EXG, and MXG X-Series Signal Generators Programming Guide 251
Creating and Downloading Waveform Files
Downloading E443xB Signal Generator Files
Downloading E443xB Signal Generator Files
To download earlier E443xB model I and Q files, use the same SCPI commands
as if downloading files to an E443xB signal generator. The signal generator
automatically converts the E443xB files to the proper file format as described
in “Waveform Structure” on page 214 and stores them in the signal
generator’s memory. This conversion process causes the signal generator to
take more time to download the earlier file format. To minimize the time to
convert earlier E443xB files to the proper file format, store E443xB file
downloads to volatile memory, and then transfer them over to non–volatile
(NVWFM) memory.
You cannot extract waveform data downloaded as E443xB files.
