Reference Agilent Part Mfr.
Designation Number Qty Part Description Code Mfr. Part Number
C506 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C512 0180-4228 2 Capacitor-Fxd 47 uF ±20% 10 V 28480 0180-4228
C551 0180-4433 2 Capacitor-Fxd 1000 uF ±20% 50 V 28480 0180-4433
C552 0180-3751 3 Capacitor-Fxd 1 uF ±20% 35 V 28480 0180-3751
C553 0180-4433 Capacitor-Fxd 1000 uF ±20% 50 V 28480 0180-4433
C554 0180-3751 Capacitor-Fxd 1 uF ±20% 35 V 28480 0180-3751
C555 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C556 0180-4435 1 Capacitor-Fxd 2200 uF ±20% 25 V 28480 0180-4435
C557 0180-4116 Capacitor-Fxd 22 uF ±20% 20 V 28480 0180-4116
C558 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C559 0180-4116 Capacitor-Fxd 22 uF ±20% 20 V 28480 0180-4116
C700-C703 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C704 0160-6729 Capacitor-Fxd 3300 pF ±10% 50 V 04222 12061C332KAT A
C705 0160-6096 Capacitor-Fxd 470 pF 50 V 04222 08051A221JAT A
C706 0180-4228 Capacitor-Fxd 47 uF ±20% 10 V 28480 0180-4228
C707-C711 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C751 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C752 0180-4434 1 Capacitor-Fxd 4700 uF ±20% 25 V 28480 0180-4434
C753 0180-3751 Capacitor-Fxd 1 uF ±20% 35 V 28480 0180-3751
CR100 1901-0638 1 Diode-Full-Wave Bridge 100V 4A 71744 KBU4B
CR103 1902-1565 3 Diode-Zener 4.7V 5% TO-236 28480 1902-1565
CR201 1902-1565 Diode-Zener 4.7V 5% TO-236 28480 1902-1565
CR202 1901-1378 1 Diode-HV Rectifier 1.6KV 500 mA 71744 GP10Y
CR203 1902-1592 Diode-Zener 5.1V 5% TO-236 28480 1902-1565
CR302-CR303 1906-0291 10 Diode-Dual 70V 100 mA TO-236AA 04713 MBAV99
CR304-CR307 1902-1541 6 Diode-Zener 3.3V 5% TO-236 04713 BZX84C3V3
CR401-CR402 1902-1541 Diode-Zener 3.3V 5% TO-236 04713 BZX84C3V3
CR403-CR404 1906-0291 Diode-Dual 70V 100 mA TO-236AA 04713 MBAV99
CR551-CR552 1906-0407 3 Diode-Full-Wave Bridge 400V 1A 71744 DF04S
CR553 1906-0291 Diode-Dual 70V 100 mA TO-236AA 04713 MBAV99
CR554 1902-1542 1 Diode-Zener 6.2V 5% TO-236 04713 BZX84C6V2
CR555-CR556 1902-1609 2 Diode-Zener 6.2V 5% PD=1.5W 04713 1SMB5920B
CR701-CR705 1906-0291 Diode-Dual 70V 100 mA TO-236AA 04713 MBAV99
CR751 1906-0407 Diode-Full-Wave Bridge 400V 1A 71744 DF04S
E100-E101 1970-0212 2 Tube Electron Surge Arrestor 1500V/10A 28480 1970-0212
E700 9164-0173 1 Alarm-Audible 25 V 28480 9164-0173
F101 2110-0780 1 Fuse (metric) 3A 250V FE UL 75915 235003
F102 2110-0614 1 Fuse (inch) 7A 250V NTD FE UL 75915 314007
FC101 2110-0869 1 Fuseholder-Horizontal PC Mnt 6.3A 250V 28480 2110-0869
FC102 2110-0565 1 Fuseholder Cap 12A Max For UL 28480 2110-0565
J701 1252-2161 1 Connector-Rect 24-CKT 24-Contact 00779 554923-2
J702-J703 1250-1884 2 Connector-RF BNC Fem 50-Ohm 00779 227161-6
Chapter 7 Replaceable Parts
34401-66501 – Main PC Assembly (A1)
128
