Keysight 34401A - Main PC Assembly (A1) Parts List

34401-66501 – Main PC Assembly (A1)
Reference Agilent Part Mfr.
Designation Number Qty Part Description Code Mfr. Part Number
C100 0160-6839 1 Capacitor-Fxd 470 pF ±2% 630 V 28480 0160-6839
C101-C103 0160-6842 3 Capacitor-Fxd 220 pF ±2% 630 V 28480 0160-6842
C104 0160-6497 36 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C105 0160-6731 3 Capacitor-Fxd 1000 pF ±10% 50 V 04222 12061C102KAT A
C106-C107 0160-5967 4 Capacitor-Fxd 100 pF ±5% 50 V 04222 08051A101JAT A
C108 0160-6736 7 Capacitor-Fxd 0.01 uF ±10% 50 V 04222 12061C103KAT A
C109 0160-8156 1 Capacitor-Fxd 0.01 uF ±20% 1 kV 56289 C023A102J103M
S38-CDH
C110 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C111 0160-5967 Capacitor-Fxd 100 pF ±5% 50 V 04222 08051A101JAT A
C113 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C120 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C150 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C151 0160-6736 Capacitor-Fxd 0.01 uF ±10% 50 V 04222 12061C103KAT A
C152 0160-6731 Capacitor-Fxd 1000 pF ±10% 50 V 04222 12061C102KAT A
C210 0160-5954 4 Capacitor-Fxd 220 pF ±5% 50 V 04222 08051A221JAT A
C212 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C301 0160-6778 1 Capacitor-Fxd 0.22 uF ±10% 400 V 14752 210BE224K
C302 0160-7605 1 Capacitor-Fxd 1.8 pF ±13.89% 1.5 kV 04222 MA30SA1R8CAA
C303 0160-6098 1 Capacitor-Fxd 680 pF ±5% 50 V 04222 12061A681JAT A
C304 0160-5973 1 Capacitor-Fxd 6.8 pF ±7.35% 50 V 04222 08051A6R8DAT A
C305 0160-6096 1 Capacitor-Fxd 470 pF ±5% 50 V 04222 12061A471JAT A
C306 0160-5972 1 Capacitor-Fxd 5.6 pF ±8.93% 50 V 04222 08051A5R6DAT A
C307 0160-5967 Capacitor-Fxd 100 pF ±5% 50 V 04222 08051A101JAT A
C308-C310 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C311-C312 0180-4116 6 Capacitor-Fxd 22 uF ±20% 20 V 28480 0180-4116
C313 0160-5955 1 Capacitor-Fxd 68 pF ±5% 50 V 04222 08051A680JAT A
C314-C315 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C316 0160-5892 2 Capacitor-Fxd .22 uF ±10% 63 V 28480 0160-5847
C317 0160-6729 2 Capacitor-Fxd 3300 pF ±10% 50 V 04222 12061C332KAT A
C318 0160-5892 Capacitor-Fxd 0.22 uF ±10% 63 V 28480 0160-5847
C319-C320 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C322-C323 0180-4116 Capacitor-Fxd 22 uF ±20% 20 V 28480 0180-4116
C324 0160-5959 2 Capacitor-Fxd 33 pF ±5% 50 V 04222 08051A330JAT A
C326 0160-6731 Capacitor-Fxd 1000 pF ±10% 50 V 04222 12061C102KAT A
C327 0160-5959 Capacitor-Fxd 33 pF ±5% 50 V 04222 08051A330JAT A
C400-C402 0160-5954 Capacitor-Fxd 220 pF ±5% 50 V 04222 08051A221JAT A
C403-C404 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C407-C410 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C411 0180-3744 1 Capacitor-Fxd 4.7 uF ±20% 10 V 28480 0180-3744
C441-C442 0160-6736 Capacitor-Fxd 0.01 uF ±10% 50 V 04222 12061C103KAT A
C449 0160-6736 Capacitor-Fxd 0.01 uF ±10% 50 V 04222 12061C103KAT A
C500-C503 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A
C504-C505 0160-6736 Capacitor-Fxd 0.01 uF ±10% 50 V 04222 12061C103KAT A
7
Chapter 7 Replaceable Parts
34401-66501 – Main PC Assembly (A1)
127
