34401-66512 – Display Assembly (A2)
Reference Agilent Part Mfr.
Designation Number Qty Part Description Code Mfr. Part Number
C602 0160-5945 3 Capacitor-Fxd 0.01uF 50 V 04222 08055C103KAT A
C603-C605 0160-6497 10 Capacitor-Fxd 0.1uF 25 V 04222 12065C104KAT A
C606-C607 0160-5947 2 Capacitor-Fxd 1000pF 50 V 04222 08055C102KAT A
C608-C609 0160-5945 Capacitor-Fxd 0.01uF 50 V 04222 08055C103KAT A
C610-C615 0160-6497 Capacitor-Fxd 0.1uF 25 V 04222 12065C104KAT A
C616-C617 0180-3751 2 Capacitor-Fxd 1uF 35 V TA S0545 NRS105M35R8
C618 0160-6497 Capacitor-Fxd 0.1uF 25 V 04222 12065C104KAT A
CR601 1906-0291 1 Diode-70V 100MA 04713 BAV99LT1
CR603 1902-1542 1 Diode-Zener 6.2V 5% 04713 BZX84C6V2
L601 9170-1431 1 Core-Shielding Bead 6352 HF50ACB-453215
M600* 33120-00611 1 Shield-ESD 28480 33120-00611
PCB1 34401-26512 1 Printed Circuit Board - Blank 28480 34401-26512
Q601 1854-1037 1 Transistor NPN SI TO-236AA PD=350MW 04713 MMBT3904LT1
R601 0699-1391 6 Resistor 10K
±1% .125W TKF TC=0±100 2M627 MCR18-F-X-1002
R602 0699-1399 2 Resistor 23.7K 1% 2M627 MCR18-F-X-2372
R603-R604 0699-1391 Resistor 10K
±1% .125W TKF TC=0±100 2M627 MCR18-F-X-1002
R605-R608 0699-1423 4 Resistor 215
±1% .125W TKF TC=0±100 2M627 MCR18-F-X-2150
R609-R610 0699-1391 Resistor 10K
±1% .125W TKF TC=0±100 2M627 MCR18-F-X-1002
R611-R612 0699-1330 2 Resistor 100K
±1% .125W TKF TC=0±100 2M627 MCR18-F-X-1003
R613 0699-1399 Resistor 23.7K 1% 2M627 MCR18-F-X-2372
R614-R617 0699-1344 4 Resistor 10
±1% .125W TKF TC=0±100 2M627 MCR18-F-X-10R0
R618 0699-1378 1 Resistor 2.61K 1% 2M627 MCR18-F-X-2611
R619 0699-1391 Resistor 10K
±1% .125W TKF TC=0±100 2M627 MCR18-F-X-1002
U601 1826-2264 1 IC-Power Management 04713 MC34064D-5
U602 34401-88813 1 Programmed 1820-8905 8-Bit MCU 28480 34401-88813
U603 1820-5330 1 IC-75518 Interface Driver, Bipolar 01295 SN75518FN
U604 1820-5562 1 IC-MC74HC02AD 01295 SN74HC02D
U605 1820-4966 1 IC-MC74HC74AD 01295 SN74HC74D
U606 2090-0296 1 Display - Vacuum Fluorescent 11908 CP3033A
U607 1826-1528 1 IC 339 Comparator 27014 LM339M
U608 1820-6756 1 74HC299-Shift Register 8 Bit Parallel 04713 MC74HC299D
U609 1826-1402 1 IC-Voltage Regulator 4.8/5.2V 04713 MC78L05ACD
W601 34401-61602 1 Cable Assembly, 8.8L 28480 34401-61602
Y601 0410-4009 1 Crystal 12MHz +1-0.8% 00830 PBRC-12.0BRN07
* M600 is shipped as a single part which breaks apart into two shields; you will use only one half of the part.
