Reference Agilent Part Mfr.
Designation Number Qty Part Description Code Mfr. Part Number
U201 1826-2420 IC-Op Amp LP Dual 8-Pin 24355 AD706JR
U301 1826-2436 1 IC-Op Amp Wideband 8-pin 27014 LF356M
U302 1826-2339 1 IC-Converter D/A 8-Bit CMOS 24355 AD7524JR
U303 1826-2437 3 IC-Op Amp Wideband 8-Pin 27014 LF357M
U304 1826-1985 1 IC Analog Switch 4 SPST 16-P-SOIC 17856 DG411DY
U305 1826-2437 IC-Op Amp Wideband 8-Pin 27014 LF357M
U306 1826-1609 1 IC-Analog Switch 4 SPST 16-P-SOIC 17856 DG211DY
U307 1826-2558 IC-Op Amp WB Sgl 8-Pin 04713 MC34081BD
U308 1826-2445 1 IC-Converter RMS/DC 16-P-SOIC MISC 24355 AD637JR
U309 1820-5790 2 IC-Shf-Rgstr CMOS/74HC Synchro 18324 74HC4094D
U310 1826-1572 1 IC-Comparator PRCN Dual 8-Pin 18324 LM393D
U311 1820-5790 IC-Shf-Rgstr CMOS/74HC Synchro 18324 74HC4094D
U312 1826-2437 IC-Op Amp Wideband 8-Pin 27014 LF357M
U400-U401 1826-2420 IC-Op Amp LP Dual 8-Pin 24355 AD706JR
U402 1826-1991 1 IC-Op Amp HS Single 8-Pin 24355 AD711JR
U403 1826-1249 1 IC-V Rgltr-V-Ref-Fxd 6.8/7.1V 28480 1826-1249
U404 1820-5937 1 IC-FF CMOS/74AC D-Type Pos-Edge-Trig 27014 74AC74SC
U405 1813-0827 1 Clock-Oscillator-XTAL 12.0MHZ 0.01% 28480 1813-0827
U411 1820-4346 1 IC Muxr/Data-Sel CMOS/74HC 2-to-1-Line 18324 74HC4053D
U420 1826-1925 IC-Op Amp Low-Noise Sgl 8-Pin 06665 OP-27GS
U500 1820-1479 1 IC-MCU Embedded 80C196 PLCC68S 34649 N80C196KB
U501 1820-8907 1 IC Gate-Array CMOS 27014 SCX6206AK0
U502 34401-88806 1 Prog EPROM (1818-5680) 28480 34401-88806
(See above) 1818-5680 1 IC 2M-BIT OTP ROM 120-ns CMOS 04078 M27C2001-12C1E
U503 1818-4777 1 IC CMOS 262144 (256K) STAT RAM 70-ns 28480 1818-4777
U505 1818-5236 1 IC 4K EEPROM 500-ns CMOS2 7014N M93C66M8
U506 1990-1552 2 Opto-Isolator LED-IC Gate IF=10 mA-Max 28480 HCPL-2211-300
U551 1826-2465 1 IC V Rgltr-Adj-Pos 1.2/37V 27014 LM317T-LB01
U552 1826-2463 1 IC V Rgltr-Adj-Neg 1.2/37V 27014 LM337T-LB01
U553 1826-2461 1 IC V Rgltr-Fxd-Pos 4.75/5.25V 27014 LM2925T-LB01
U700 34401-88842 1 Micro Proc (1821-0015) 28480 34401-88842
(See above) 1821-0015 1 IC-8-Bit MCU w/8K EPROM & Prgmbl Cntr 34649 N87C51FA
U701 1822-0639 1 IC-GPIB Controller IEEE-488 1975/78 01295 TMS9914AFNL
U702 1820-6176 1 IC-Interface GPIB Octal Data XCVR 01295 SN75ALS160DW
U703 1820-6175 1 IC-Interface XCVR Bipolar Bus Octl 01295 SN75ALS162DW
U704 1990-1552 Opto-Isolator LED-IC Gate 28480 HCPL-2211-300
U705 1820-6470 1 IC-Schmitt-Trigger CMOS/74HCT 18324 74HCT14D
U706 1820-7662 1 IC-Interface Drvr/Rcvr Bipolar Dual 28480 1820-7662
U751 1826-2464 1 IC V Rgltr-Fxd-Pos 4.8/5.2V 27014 LM340T-5-LB01
US403 1200-1672 1 Socket-IC-DIP 4 Contact Dip-Sldr 06776 SBL-041-SP122-TG30
XF102 2110-0690 1 Fuseholder-Bipin-Socket 16A 250V UL 28480 2110-0690
Y701 0410-4009 1 Crystal-Quartz 12.0 MHz 28480 0410-4009
Chapter 7 Replaceable Parts
34401-66501 – Main PC Assembly (A1)
132
