Reference Agilent Part Mfr.
Designation Number Qty Part Description Code Mfr. Part Number
R430 0699-1503 1 Resistor Zero Ohm 28480 0699-1503
R440 0699-1406 Resistor 42.2K ±1% .125W 28480 0699-1406
R441 0699-1394 Resistor 14.7K ±1% .125W 28480 0699-1394
R442 0699-2127 1 Resistor 36.5K ±1% .125W 28480 0699-2127
R449 0699-1415 1 Resistor 100 ±1% .125W 28480 0699-1415
R501 0699-1318 Resistor 1K ±1% .125W 28480 0699-1318
R502 0699-1330 Resistor 100K ±1% .125W 28480 0699-1330
R503 0699-1423 Resistor 215 ±1% .125W 28480 0699-1423
R504 0699-1391 Resistor 10K ±1% .125W 28480 0699-1391
R505-R506 0699-1386 2 Resistor 5.62K ±1% .125W 28480 0699-1386
R507 0699-1391 Resistor 10K ±1% .125W 28480 0699-1391
R508-R509 0699-1318 Resistor 1K ±1% .125W 28480 0699-1318
R510-R511 0699-1391 Resistor 10K ±1% .125W 28480 0699-1391
R512-R517 0699-1423 Resistor 215 ±1% .125W 28480 0699-1423
R518 0699-1391 Resistor 10K ±1% .125W 28480 0699-1391
R551 0699-1424 2 Resistor 237 ±1% .125W 28480 0699-1424
R552 0699-2431 1 Resistor 3.32K ±1% .125W 28480 0699-2431
R553 0699-1424 Resistor 237 ±1% .125W 28480 0699-1424
R554 0699-1380 Resistor 3.16K ±1% .125W 28480 0699-1380
R555 0699-1406 1 Resistor 42.2K ±1% .125W 28480 0699-1406
R556 0699-1391 Resistor 10K ±1% .125W 28480 0699-1391
R701 0699-3408 1 Resistor 1K ±5% 1W 91637 CRCW2512-102J
R702 0699-1398 Resistor 21.5K ±1% .125W 28480 0699-1398
R703 0699-1391 Resistor 10K ±1% .125W 28480 0699-1391
R704 0699-1330 Resistor 100K ±1% .125W 28480 0699-1330
R705 0699-1318 Resistor 1K ±1% .125W 28480 0699-1318
R706 0699-3407 1 Resistor 100 ±5% 1W 91637 CRCW2512-101J
R707-R708 0699-1318 Resistor 1K ±1% .125W 28480 0699-1318
R709 0699-1380 Resistor 3.16K ±1% .125W 28480 0699-1380
R720 0699-1374 Resistor 1.78K ±1% .125W 28480 0699-1374
R750-R751 0699-1318 Resistor 1K ±1% .125W 28480 0699-1318
RV100-RV102 0837-0382 3 Diode-Varistor 1.1KV 28480 0837-0382
S1 3101-3162 1 Switch-Pushbutton .4A 25 VAC/VDC 71468 603296
U101 1SK6-0001 1 Switch Chip 28480 1SK6-0001
U102 1NB4-5035 1 Resistor Network 28480 1NB4-5035
U103 1826-2420 5 IC-OP Amp LP Dual 8-Pin 24355 AD706JR
U104 1855-0864 1 Transistor-JFET Dual 27014 NPDSU406
U105 1826-2558 3 IC-OP Amp WB Sgl 8-Pin 04713 MC34081BD
U106 1826-1925 2 IC-OP Amp Low-Noise Sgl 8-Pin 06665 OP-27GS
U110 1826-2558 IC-OP Amp WB Sgl 8-Pin 04713 MC34081BD
U150 1820-8937 1 IC Gate-Array CMOS 27014 SCX6B04AKP
U153 1826-2420 IC-OP Amp LP Dual 8-Pin 24355 AD706JR
7
Chapter 7 Replaceable Parts
34401-66501 – Main PC Assembly (A1)
