34401-66522 Display Assembly Replaceable Parts List

Reference Agilent Part Mfr.

Designation Number Qty Part Description Code Mfr. Part Number

C600-C601 0160-6497 4 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A

C602-C604 0180-3751 3 Capacitor-Fxd 1 uF ±20% 35 V 28480 0180-3751

C605 0160-6736 3 Capacitor-Fxd 0.01 uF ±10% 50 V 04222 12061C103KAT A

C608-C609 0160-6497 Capacitor-Fxd 0.1 uF ±10% 50 V 04222 12065C104KAT A

C620-C621 0160-6731 2 Capacitor-Fxd 1000 pF ±10% 50 V 04222 12061C102KAT A

C622-C623 0160-6736 Capacitor-Fxd 0.01 uF ±10% 50 V 04222 12061C103KAT A

CR600 1902-1544 1 Diode-Zener 10V 5% TO-236 Pd=.35W 04713 BZX84C10

CR601 1906-0291 2 Diode-Dual 70V 100 mA 04713 MBAV99

CR603 1906-0291 Diode-Dual 70V 100 mA 04713 MBAV99

CR604-CR605 1906-0337 4 Diode-Dual 60V 200 mA2 84801 906-033

CR606 1902-1565 1 Diode-Zener 4.7V 5% 28480 1902-1565

CR608-CR609 1906-0337 Diode-Dual 60V 200 mA 28480 1906-0337

M600* 33120-00611 1 Shield-ESD 28480 33120-00611

PCB1 34401-26502 1 Printed Circuit Board - Blank 28480 34401-26502

R600 0699-1322 1 Resistor 68.1K ±1% .125W 28480 0699-1322

R602 0699-1378 1 Resistor 2.61K ±1% .125W 28480 0699-1378

R603 0699-1399 1 Resistor 23.7K ±1% .125W 28480 0699-1399

R604 0699-1398 1 Resistor 21.5K ±1% .125W 28480 0699-1398

R605-R606 0699-1330 6 Resistor 100K ±1% .125W 28480 0699-1330

R609-R611 0699-1396 3 Resistor 17.8K ±1% .125W 28480 0699-1396

R620-R623 0699-1423 4 Resistor 215 ±1% .125W 28480 0699-1423

R640-R641 0699-1330 Resistor 100K ±1% .125W 28480 0699-1330

R643-R644 0699-1330 Resistor 100K ±1% .125W 28480 0699-1330

RP601 1810-1360 1 Network-Res 16-SMD 10.0K Ohm x 8 91637 SOMC-1603-103G

U600 1820-8985 1 IC-MCU w/FIP Driver 28480 1820-8985

U601 1820-5805 1 IC-Shf-Rgtsr CMOS/74HC Bidir 01295 SN74HC194DW

U602 1826-1528 1 IC-Comparator LP Quad 27014 LM339M

U603 2090-0296 1 Display-Vacuum Fluorescent 28480 2090-0296

W601 34401-61602 1 Cable Assy 8.8"L 0.236/0.157" Strip 28480 34401-61602

* M600 is shipped as a single part which breaks apart into two shields; you will use only one half of the part.

Chapter 8 Backdating

Agilent 34401A Multimeter

139
