2 Using the Oscilloscope
Learning the Oscilloscope Display
The user interface is arranged so the most common functions affecting the
waveform display are located around the edge of the waveform display area.
Context-sensitive menus are available by right-clicking something in the waveform
display area, such as a grid, a signal, a bookmark, or a measurement. You can
mouse over or touch other areas, such as the drag & drop measurements area and
horizontal and acquisition control regions, to find more information about those
areas or to enter data.
Figure 9 Infiniium display
Open Add Markers
dialog box
Zoom
on/off
Set
horizontal
position
Set
horizontal
scale
Open Horizontal
dialog box
Expand drag/drop
measurements
Customize
Results display
Drag/drop
measurements
Open Channel
dialog box
Ground indicator
Grid selection modes:
Set trigger level
Undo/Redo
drag draw
Trigger slope
Open Trigger
dialog box
Memory barPin/unpin
controls
Add
waveforms
Open Acq.
dialog box
Set vertical
offset
Clear
display
Set vertical
scale
Acquisition
run controls
Menu bar
Bandwidth
details
waveform rectangle
