E-Series Power Sensor Specifications
The E-Series of power sensors have their calibration factors stored in EEPROM and operate over a wide dynamic range� They are
designed for use with the EPM Series of power meters and two classes of sensors are available:
– CW power sensors (E4412A and E4413A)
– Average power sensors (E9300 sensors)
E-Series CW Power Sensor Specifications
Widest dynamic range: 100 pW to 100 mW (–70 to +20 dBm)
Table 4. E4410 Series max SWR specification.
Model Maximum SWR Maximum SWR Maximum power Connector type
E4412A 10 MHz to 18 GHz 10 to < 30 MHz: 1.22
1
200 mW (+23 dBm) Type-N (m)
30 MHz to < 2 GHz: 1.15
2 to < 6 GHz: 1.17
2
6 to < 11 GHz: 1.2
11 to 18 GHz: 1.27
3
E4413A 50 MHz to 26.5 GHz 50 to < 100 MHz: 1.21 200 mW (+23 dBm) APC-3.5 mm (m)
100 MHz to < 8 GHz: 1.19
8 to < 18 GHz: 1.21
4
18 to 26.5 GHz: 1.26
5
1� Applies to sensors with serial prefix US 3848 or greater�
2� Max SWR is 1�2 for high power from +17 to +20 dBm�
3� Max SWR is 1�34 for high power from +17 to +20 dBm�
4� Max SWR is 1�28 for high power from +17 to +20 dBm�
5� Max SWR is 1�49 for high power from +17 to +20 dBm�
N1913A/14A EPM Series Power Meters Ordering Information (Continued)
Options (Continued)
Documentation
N191xA-0B1 Hard copy English language User’s Guide and Installation Guide
N191xA-0BF Hard copy English language Programming Guide
N191xA-0BW Hard copy English language Service Guide
N191xA-ABA Hard copy English language User’s Guide and Programming Guide
N191xA-ABJ Hard copy Japanese localization User’s Guide and Programming Guide
N1913A-CD1 Documentation Optical Disk (consists of documentation CD-ROM and Keysight Instruments Control DVD)
