1-6 Electronic Calibration Modules Reference Guide
General Information
Models and Options
1-
Table 1-1 N755xA Modules
Model
Number
Connector
Type
Operating
a
Frequency
Port A and B Option
-m- and -f- -m- and -m- -f- and -f-
N7550A Type-N 50 ohm DC to 4 GHz N7550A-NMF N7550A-NMM N7550A-NFF
3.5 mm N7550A-3MF N7550A-3MM N7550A-3FF
N7551A
Type-N 50 ohm
DC to 6.5 GHz
N7551A-NMF N7551A-NMM N7551A-NFF
3.5 mm N7551A-3MF N7551A-3MM N7551A-3FF
N7552A
Type-N 50 ohm
DC to 9 GHz
N7552A-NMF N7552A-NMM N7552A-NFF
3.5 mm N7552A-3MF N7552A-3MM N7552A-3FF
N7553A
Type-N 50 ohm
DC to 14 GHz
N7553A-NMF N7553A-NMM N7553A-NFF
3.5 mm N7553A-3MF N7553A-3MM N7553A-3FF
N7554A
Type-N 50 ohm
DC to 18 GHz
N7554A-NMF N7554A-NMM N7554A-NFF
3.5 mm N7554A-3MF N7554A-3MM N7554A-3FF
N7555A 3.5 mm DC to 26.5 GHz N7555A-3MF N7555A-3MM N7555A-3FF
a. Option 0DC frequency range is DC to xx.x GHz. Option 100 frequency range is 10 MHz to xx.x GHz.
N755xA Other
Options
Description
A6J ANSI Z540-1-1994 Calibration
1A7 Calibration + Uncertainties + Guardbanding
UK6 Adds commercial calibration certificate with measured data.
SPS Post Sales Support
150 ECal ruggedized plastic storage box – See also “ECal Kit Storage Box (Option 150) –
(N755xA Only)” on page 4-23
