Replaceable Parts 6
Model N6705 Service Guide 119
Reference
Designator
Keysight N6705A
Keysight N6705B
Description
Cables
31 5185-8809 5185-8809 AC in to filter cable
32 E5810-61605 E5810-61605 GPIB and Cable
33 5185-8811 5185-8811 48 V Rail to Backplane 1 & 2 cable
34 5185-8812 5185-8812 Sense cable
35 5185-8813 5185-8813 Bias to PPMC cable
36 5185-8819 5185-8819 (2) PPMC to Backplane 1; PPMC to Backplane 2
37 5185-8821 5185-8821 Display to front panel cable
38 5185-8810 5185-8810 Bulk supply to line switch cable
39 5185-8823 5185-8823 PPMC to front panel cable
40 N1912-61002 N1912-61002 Backlight cable assembly
41 5185-8824 5185-8824 Bulk supply ground wire
47 5067-4311 (2) 5067-4311 (2) Bias to Backplane 1; Bias to Backplane 2
48 5185-8825 5185-8825 Filter to line switch cable
49 D8104-61602 D8104-61602 Front panel USB cable
50 N/A 5067-4385 (2) Auxiliary Voltage PCA
51 N/A 9170-2264 (4) Front panel cable inductor
52 N/A 0400-1009 (4) Rear panel cable grommet
Handle Assembly and Label
42
E4400-40018
E4400-40018
End cap
43
E6601-21033
E6601-21033
Handle retainer
44
N6705-60002
N6705-60002
Strap handle
45
N6705-60003
N6705-60003
Strap insert
46
N6705-80001
N6705-80001
Mainframe label
* Part number for units without fan speed control
A2
N6705-60102
Tested Bias PCA for N6705A
19
5065-7094
Backplane 1 PCA
20
5065-7095
Backplane 2 PCA
21
5067-2520
Fan assembly
Fan speed-control serial numbers
Automatic fan speed controls have been installed in all N6705A
mainframes with the following serial numbers:
MY47000757 - MY47000758
MY47000765 - MY47000766
MY47000789 - MY47000793
MY47000804 and up
SG47000140 and up
All N6705B mainframes have automatic fan speed controls.
