Keysight N6705 - Calibration Procedure - Models N6783 A-BDA and -MFG

3 Calibration
76 Model N6705 Service Guide
Calibration Procedure – Models N6783A-BDA and -MFG
Enter Calibration mode
Front Panel:
SCPI Command:
Press [Menu], then select Utilities,
Administrative Tools, Administrator Login.
Enter yo
ur numeric password in the PIN field
and select Login.
Then select the Calibration menu. Select
Turn On/Off to access the menu items.
CAL:STAT ON,
<password>
Voltage Calibration
High Range Programming and Measurement
Step 1.
Connect the voltage input of the Keysight 3458A DMM to an output
channel (see Cal Setup A).
Step 2.
Select the full-scale voltage programming and measurement range. The
value entered must be the maximum voltage of the range that you are
calibrating. The following example selects the 6 V full-scale range of
output 1. Full-scale ranges vary according to model.
Front Panel:
SCPI Command:
From the Calibration menu, select Voltage,
High Range Prog and Meas. Then select
Start.
CAL:VOLT 6, (@1)
Step 3.
Select the first voltage calibration point.
Front Panel:
SCPI Command:
The first calibration point is automatically
selected. “Enter P1 measured data” should be
displayed.
CAL:LEV P1
*OPC?
Step 4.
Measure the output voltage with the DMM and enter the data.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next.
CAL:DATA <data>
Step 5.
Select the second voltage calibration point.
Front Panel:
SCPI Command:
The second calibration point is automatically
selected. “Enter P2 measured data” should
be displayed.
CAL:LEV P2
*OPC?
