Calibration 3
Model N6705 Service Guide 49
Calibration Procedure – Models N675xA
Enter Calibration mode
Front Panel:
SCPI Command:
Press [Menu], then select Utilities,
Administrative Tools, Administrator Login.
Enter your numeric password in the PIN
field and select Login.
Then select the Calibration menu. Select
Turn On/Off to access the menu items.
CAL:STAT ON,
<password>
Voltage Calibration
High Range Programming and Measurement
Step 1.
Connect the voltage input of the Keysight 3458A to an output channel
(see Cal Setup A).
Step 2.
Select the full-scale voltage programming and measurement range. The
value entered must be the maximum voltage of the range that you are
calibrating. This example selects the 50 V full-scale range of output 1.
Full-scale ranges vary according to model.
Front Panel:
SCPI Command:
From the Calibration menu, select Voltage,
High Range Prog and Meas. Then select
Start.
CAL:VOLT 50, (@1)
Step 3.
Select the first voltage calibration point.
Front Panel:
SCPI Command:
The first calibration point is automatically
selected. “Enter P1 measured data” should be
displayed.
CAL:LEV P1
*OPC?
Step 4.
Measure the output voltage with the DMM and enter the data.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next.
CAL:DATA <data>
Step 5.
Select the second voltage calibration point.
Front Panel:
SCPI Command:
The second calibration point is automatically
selected. “Enter P2 measured data” should
be displayed.
CAL:LEV P2
*OPC?
