3 Calibration
52 Model N6705 Service Guide
Step 4.
Set the electronic load or connect the appropriate resistor for the second
calibration point.
Step 5.
Select the second current calibration point.
Front Panel:
SCPI Command:
Select Next. The calibration is automatic.
Then select Close.
CAL:LEV P2
*OPC?
Downprogrammer Calibration
Step 1.
Remove all loads from the output. This procedure is automatic and takes
a few seconds.
Front Panel:
SCPI Command:
From the Calibration menu, select
Miscellaneous, Downprogrammer, then
Start. Then select Close.
CAL:DPRog (@1)
*OPC?
Enter a Calibration Date
Front Panel:
SCPI Command:
From the Calibration menu, select
Date. Enter the date in the format
“yyyy/mm/dd”. Then select Insert
Date. Then select Close.
To enter a calibration date:
CAL:DATE “<date>”,
(@1)
Save and Log out of Calibration Mode
CAUTION
Storing calibration constants overwrites the existing ones in non-volatile
memory. If you are not sure you want to permanently store the new
constants, do not Save the data when you exit the calibration mode. The
calibration will then remain unchanged.
Front Panel:
SCPI Command:
From the Calibration menu, select
Save. Then select Save Calibration
for all Outputs. Select Close.
Go [Back] to the Administrative
tools menu and select
Administrator Login. Select Logout,
then Close
To save calibration data:
CAL:SAVE
To exit calibration mode:
CAL:STAT OFF
