Calibration 3
Model N6705 Service Guide 55
Step 5.
Measure the output voltage with the DMM and enter the data.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next. When
calibration is complete, select Close.
CAL:DATA <data>
Low Range Voltage Measurement
Step 1.
Select the low-voltage measurement range. The value entered must be
the maximum voltage of the range to be calibrated. This example selects
the 5 V measurement range of output 1.
Front Panel:
SCPI Command:
From the Calibration menu, select
Voltage, Low Range Measurement. Then
select Start.
CAL:VOLT:MEAS 5, (@1)
Step 2.
Select the first voltage calibration point.
Front Panel:
SCPI Command:
The first calibration point is automatically
selected. “Enter P1 measured data” should
be displayed.
CAL:LEV P1
*OPC?
Step 3.
Measure the output voltage with the DMM and enter the data.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next.
CAL:DATA <data>
Step 4.
Select the second voltage calibration point.
Front Panel:
SCPI Command:
The second calibration point is automatically
selected. “Enter P2 measured data” should
be displayed.
CAL:LEV P2
*OPC?
Step 5.
Measure the output voltage with the DMM and enter the data.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next. When
calibration is complete, select Close.
CAL:DATA <data>
