Keysight PXA Series User Manual

20 Installation Note N9030-90058
Option EXM, External Mixing Upgrade Kit
5. Refer to Figure 15. Use a ¼” open-end wrench to prevent the SMA female connector on W17 from
twisting. Use a 5/16” torque wrench to torque the nut on W29 to 10 inch-pounds.
Figure 15 Torque Cable W29 onto W17

Keysight PXA Series Specifications

General

Frequency Range	3 Hz to 50 GHz (depending on model)
Phase Noise	-136 dBc/Hz at 1 GHz and 10 kHz offset (typical)
Resolution Bandwidth	1 Hz to 10 MHz
Input Impedance	50 Ohm
Dimensions	177 mm (H) x 426 mm (W) x 470 mm (D)
