Keysight PXA Series User Manual

Installation Note N9030-90058 21
Option EXM, External Mixing Upgrade Kit
Top Brace Replacement
1. Refer to Figure 16. To replace the top brace, place the brace in the correct position and attach to the
chassis using the twelve screws (3) (0515-0372). Attach the top brace to the boards using the
twelve screws (14 screws with Option B1X) (4) (0515-1227).
2. Refer to Figure 17. Reinstall wire hold down 1.
3. Torque all screws to 9 inch-pounds.
Figure 16 Top Brace Replacement

Keysight PXA Series Specifications

General

Frequency Range	3 Hz to 50 GHz (depending on model)
Phase Noise	-136 dBc/Hz at 1 GHz and 10 kHz offset (typical)
Resolution Bandwidth	1 Hz to 10 MHz
Input Impedance	50 Ohm
Dimensions	177 mm (H) x 426 mm (W) x 470 mm (D)
