1. Prepare a hole in the wall. Install the wall
exhaust adapter onto the wall by using 4
expansion screw sleeves and type C
screws, be sure to fix thoroughly.
2. Connect the exhaust duct to the wall
exhaust adapter. (Fig. G)
INSTALLATION
Install the exhaust duct into the wall
* During dehumidifying mode, remove the upper drain plug from the back of the unit.
Attach the drain hose to the hole. Place the other end of the hose in the drain or other
drain location.
Water drainage
Note: 1. The duct can be compressed to 27cm minimum and extended to 150cm
maximum. It is better to keep the duct length to a minimum length.
2. Stretching or bending the duct excessively will affect the cooling
efficiency. (As the following fig. shows)
No! Yes!
- 13 -
