2. Connect the exhaust duct to the Air outlet connector on the back of
the unit. Slide in the adapter A downwards until it is locked in place.
(Fig. C)
1. Cut the foam seal (adhesive type) to the proper length and attach it
to the window sash.
INSTALLATION
Install the Window Slider Kit
2. Attach the Window Slider Kit to the window sash. Adjust the length of
the Window Slider Kit: loosen screw A to adjust the length of the
Window Slider Kit, then tighten the screw when the length is suitable.
Note: the length of the Window Slider Kit is 67.5 cm to 120 cm.
- 15 -
