INSTALLATION
Observe all governing codes and ordinances. Check the location where the air
conditioner will be installed. Ensure everything necessary for the correct installation
is available.
1. Install the portable air conditioner in a flat and open location where the air outlets
will not be obstructed.
2. Keep the minimum clearance from walls or other obstacles, as shown.
3. A level floor is required with maximum gradient of 10 degrees with the horizontal
plane is require to place the unit.
1. Install the adapter A and adapter B (flat mouth or round mouth) into the exhaust
duct as shown in Fig. A or Fig. B.
Unit Placement
• In cooling, heating, and drying mode, the exhaust duct needs to be installed.
While in fan mode, the exhaust duct is not needed.
• According to the actual needs, the exhaust duct can be moderately compressed
and tensed, but cannot be arbitrarily stretched and bent.
• The exhaust duct can be connected with Windows or installed into the wall. With
the actual needs, you can make the installation with accessories of the unit.
Duct mount instruction
Note:
1. The air conditioner should not be used in the laundry
room or other confined space.
2. The plug should be accessible after the unit is positioned.
1. Install the mobile air conditioner in a flat and
open location where the air outlets will not
be obstructed.
2. Keep the minimum clearance from walls or other
obstacles, as shown.
3. A level floor is required with maximum gradient
of 10 degrees with the horizontal plane is
required to place the unit.
- 16 -
