KHE ACS SERIES – USER MANUAL www.KHE-AudioElectronics.com 22 / 23
RACK SPACE DIMENSIONS WEIGHT
ACS 4x2: 1 U
1/2
19″ 170mm x 180mm x 44mm 1.5kg
ACS 4x4: 1 U 19” 483mm x 200mm x 44mm 3.0kg
ACS 4x4 FX: 1 U 19” 483mm x 200mm x 44mm 3.2kg
ACS 8x4: 1 U 19” 483mm x 200mm x 44mm 3.5kg
ASX 8: 1 U 19” 483mm x 200mm x 44mm 3.4kg
CSX 8: 1 U 19” 483mm x 200mm x 44mm 2.8kg
AFX 8: 1 U 19” 483mm x 200mm x 44mm 2.9kg
Power Supply: external, desktop style, included
Input Voltage: 100 – 240V AC, 50 – 60 Hz, 0.6A, SK1
OutputVoltage: 15V DC, 1.2A, 18W
Connector PSU: USA, EU, UK, AU, CH, 3-pin
Power Consumption: 10 Watt max.
Amplifier and Load Rating: 150 Watt max pass thru
Instrument Input Impedance: 2,2MOhm
Instrument Output Impedance: < 1kOhm
FX-Loop Impecances: 1 Mohm
Switching Time: 3 – 15ms per operation
Crosstalk Level: < 100dBu
Max. Guitar Input Level: +15Vpp / +18dBu
Frequency Range: 10-100kHz, +/-0.2dB
Noise Floor: < 100dBu
Note: device specifications are subject to change without notice.
All KHE ACS units are covered by a 2-year warranty. KHE Audio Electronics shall not be liable if the damage was
caused by inappropriate use or if the units are not connected as described in this user manual. Damage to this
device by improperly connected and/or grounded equipment is not covered under warranty. There are no user
serviceable parts inside the unit. The detailed terms of the warranty can be downloaded on the KHE website. If
you need technical support, please contact your local dealer or email info@khe-audioelectronics.com.
Warranty claims and returned units will be rejected or charged with additional charges if not returned in the
original box with the foam inlet.
TECHNICAL SPECIFICATIONS
WARRANTY
