ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS.
*IF EQUIPPED
Active ECO System
Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
www.KuTechVideos.com/jf13/2017
The ECO Mode system helps improve fuel economy
by controlling several vehicle components. When
activated, it optimizes drivetrain operations such as
engine power and transmission to help improve fuel
economy.
To turn ON, press DRIVE MODE*
B
or the ECO Mode
button. The button light will turn on, and the green
ECO indicator light
C
in the instrument cluster will
illuminate (indicating that you are getting optimal
fuel efficiency). The ECO Mode system will remain
on even when the ignition is cycled.
To turn the ECO Mode system OFF, press DRIVE
MODE*
B
or the ECO Mode button again.
For more information on ECO Mode, refer to your Owner’s Manual or contact your local dealership.
7
8
20
40
60
80
100
120
140
160
0
MPH
km/h
0
20
40
60
80
100
120
140
160
180
200
220
240
260
x1000rpm
ECO
SPORT
(Type C - Located below gear shift)
(Located in Instrument Cluster)
To help improve your fuel economy:
• Drive at a moderate speed, accelerating smoothly and at a moderate rate
• Keep tires inflated to the recommended pressure
• Be sure the wheels are properly aligned
QUICK TIPS
A
B
C
QR CODE
Drive Mode Integrated Control System* ECO Mode (Active ECO)*
The Drive Mode may be selected depending on driver’s
preferences and road conditions.
To cycle through the different Drive Modes
A
, press the DRIVE
MODE button
B
. The Instrument Cluster will display SPORT or
ECO when selected. When in Normal mode, it will not display in
the Instrument Cluster.
REMINDERS:
• The system is turned ON and in Normal mode when ignition is in the
ON position
• When ECO mode is selected, the indicator will display and system remains on,
even when ignition is cycled
INSTRUMENT CLUSTER
