ATTACHING THE FAN BLADES
NOTE: Before continuing , make sure the power is disconnected by turning
o the circuit breaker of removing the fuse at the circuit box.
Step 1. Lightly attach the blade to the motor body with washers and screws
found in the blade attachment hardware pack. Then, securely tighten after
two screws are attached.(Fig.16)
12
Fig. 17
Fig. 16
Step 1. Remove one of three mounting plate screws preinstalled on
mounting plate and keep for later use. Loosen the other two (do not
remove).(Fig.17)
NOTE: Before continuing installation, confirm that the power is still turned
o at the main circuit breaker or by removing the circuit fuse. Turning the
power o using a wall switch is not sucient to prevent electrical stock.
INSTALLING THE SWITCH HOUSING
Motor Body
Blade
Washer
Screw
Mounting Plate
Screw
