Kidde 10SDR-CA - Page 10

10
30.5cm
(12in )
MAXIMUM
30.5cm
(12in )
MAXIMUM
10 cm
(4in)
MINIMUM
10 cm
(4in)
MINIMUM
BEST
HERE
NEVER
HERE
ACCEPTABLE
HERE
CEILING
SIDE
WALL
SIDE
WALL
CEILING
DEAD AIR
SPACE
ACCEPTABLE
TOP OF ALARM
ACCEPTABLE HERE
Note: measurements shown
are to the closest edge
of the alarm.
Note: measurements shown
are to the closest edge
of the alarm.
NOT IN
THIS AREA
ANYWHERE IN
THIS AREA
0.9 m (3ft) 0.9 m (3ft)
HORIZONTAL DISTANCE
FROM PEAK
ANYWHERE IN
THIS AREA
30 cm
(12in)
NOT IN
THIS AREA
ANYWHERE IN
THIS AREA
0.9 m (3ft)
20 cm (7.8in)
ACCEPTABLE
PLACEMENT
MAXIMUM
MAXIMUM
20 cm (7.8in)
30.5cm
(12in )
MAXIMUM
10 cm
(4in)
MINIMUM
10 cm
(4in)
MINIMUM
BEST
HERE
NEVER
HERE
SIDE
WALL
ACCEPTABLE
HERE
CEILING
DEAD AIR
SPACE
Figure 6-A
