Chapter 2: Smoke control system hardware
36 VM-1 Smoke Management Application Guide
Table 8: VAV smoke control settings
Smoke
zone Adjacent zones Central VAV system Remote zones on same central system
Supply fan ON
Return fan ON
Exhaust air damper OPEN
Exhaust air damper CLOSED Exhaust air damper OPEN Exhaust air damper CLOSED
Supply air damper CLOSED
Supply air damper OPEN Outside air damper OPEN Supply air damper CLOSED
Terminal unit discharge
damper OPEN
Return air damper CLOSED
Reset static pressure control to
maximize air flow and prevent duct
failure
FSCS firefighter smoke
control station
The FSCS, where required, is most often located in the
building’s fire command center. The FSCS is a remotely
networked panel, which also contains an FSCS series
graphic annunciator. Where the fire command center is
also located in the building’s central security center, an
SCS with a graphic annunciator may also serve as the
FSCS.
The FSCS series graphic annunciator, with network
support hardware, is capable of providing both
monitoring and manual control of smoke control system
components. The graphic annunciator, when combined
to the correct Signature Series modules, can be used by
firefighters to start and stop fans and open and close
dampers for smoke control. The system, while designed
primarily for occupant protection and egress, can be
used by firefighters to exhaust smoke and allow for
effective fire attack and extinguishment by manual
means.
VM-1 SCS
Smoke control systems, which are not interconnected as
part of an VM-1 fire alarm network panel, constitute a
stand-alone system. The descriptions of components
which follow address a stand-alone smoke control
system, but can also be applied to a FACP function with
the smoke control system components sharing common
inputs and hardware in the VM-1 fire alarm network
panel.
Table 9: VM-1 components
Model
Description
CAB6B
Control panel back box
VMD(G/R)
Control panel door
VM
-CPU CPU main board and dual loop controller
C
-CPUD CPU daughter card
VM
-LCD LCD user interface
PS10
-4B Power supply
VM
-NOC Network option card, RS-485, 8 nodes, max.
VM
-NOCF Network option card, fiber optic, 8 nodes, max.
VM
-ETH1 Ethernet adapter card
VM
-DACT Dual line dialer
VM
-SLCXB Signaling line loop controller expansion card
CLA
-PS10 Class A NAC adapter card
D12LS
-VM Annunciator strip with 12 LED-switch groups.
Each group consists of one switch and one
programmable LED (amber, red, blue, or green)
over an amber LED
VMI
-PMI Paging microphone interface
VM
-MFK Firefighter's telephone kit
ACHS
Audio channel selector cards
CDR
-3 Coder module
RPM
Reverse polarity module
CTM
City tie module
GCI
Graphic annunciator interface card
GCI
-NB Graphic annunciator interface card
GCIX
Graphic annunciator expander card
