Chapter 2: Smoke control system hardware
VM-1 Smoke Management Application Guide 37
FSCS series graphic
annunciator
Description
The FSCS series graphic annunciator provides detailed
information on the location of dampers, barriers, and
fans. The graphic annunciator may display a single
smoke zone, a floor, or an entire building. Panel control
functions, tailored to firefighter smoke control needs,
include the actual status of smoke control equipment
and components, which are capable of activation. LED
confirmation of individual fans sensed by pressure
difference and indications of damper position can be
designed into the graphic annunciator, the companion
LCD display, and the LED switches. The FSCS series
graphic annunciator receives its power from the VM-1
network.
Table 10: FSCS series graphic annunciator components
Model
Description
EV1B
Back box, 24 × 18 × 3.5 in. (610 × 458 × 89 mm)
EV2B
Back box, 24 × 24 × 3.5 in. (610 × 610 × 89 mm)
EV3B
Back box, 24 × 36 × 3.5 in. (610 × 915 × 89 mm)
EV4B
Back box, 36 × 48 × 3.5 in. (914 × 1219 × 89 mm)
3
-EVRMF Graphic annunciator inner door mounting bracket
EVZSLED
In-graphic LED, red, yellow, or green
EVZSBLED
In-graphic LED, blue
EVZSWLED
In-graphic LED, white
EVSC3
-21 Two-position toggle switch
EVSC3
-22 Two-position toggle switch
EVSC3
-32 Three-position toggle switch
EVSC3
-33 Three-position toggle switch
EVSC3R
-21 Two-position rotary switch
EVSC3R
-22 Two-position rotary switch
EVSC3R
-32 Three-position rotary switch
EVSC3R
-33 Three-position rotary switch
EVSC3R
-44 Four-position rotary switch
EVKE
Enable key switch
EVPLED
Power LED
EVTLED
Trouble LED
Model
Description
EVSSLED
Signal silence LED
EVTS
Trouble silence switch
EVDRILL
Drill switch
EVLT
Lamp test push button
GCI
Graphic annunciator interface card
GCI
-NB Graphic annunciator interface card
GCIX
Graphic annunciator expander card
Fan control and monitor
circuit
Figure 23 on page 38 shows a typical fan control and
monitor circuit. During normal operation, the fan (item 1)
is off and may be turned on by either the HVAC system
or by the automatic fire detection system. During alarm
operation, the automatic fire detection system activates
the GSA-IO module (item 5), which energizes relay K1
and connects the line voltage to the fan.
The GSA-IO module (item 5) also monitors the air flow
switch (item 2) used to signal when the fan reaches the
required output capacity. The GSA-IO module activates
a Monitor event when the switch closes or a Trouble
event if the switch fails to close in the time allowed.
The GSA-IO module (item 6) monitors the air flow switch
(item 3) used to signal when the fan is not operating.
The GSA-IO module activates a Monitor event when the
switch closes or a Trouble event if the switch fails to
close in the time allowed.
The GSA-CT1 module monitors the end-of-line power
supervision relay (K2) and activates a Trouble event on
loss of 24 VDC.
Notes
• Install relay K1 ahead of the HVAC system
controller.
• The NFPA 72 Code requires that the wire distance
between control devices and air handling units
(AHUs) does not exceed 36 in. (91.44 cm).
• 24 VDC is from a regulated and filtered power
supply that is UL/ULC Listed for fire protective
signaling service.
