4 User’s Manual PXB series
• In this manual, units of Bidirectional DC Power Supply
PXB20K-500, PXB20K-1000, and PXB20K-1500 refer to
as “PXB series”
• In this manual, constant voltage, constant current, and
constant power may refer to as CV, CC, and CP,
respectively.
• “PC” in this manual is a generic term for personal
computers and workstations.
• The term “DUT”
is used to refer generally to a device
under test.
• The screen captures and illustrations used in this
manual may differ from the actual items.
• The following markings are used in this manual.
Indicates a potentially hazardous situation which, if
ignored, could result in death or serious injury.
Indicates a potentially hazardous situation which, if
ignored, may result in slight injury or damage to the
product and other property.
Indicates information that you should know.
>
Indicates the hierarchy of items you need to select. The item
to the left of this symbol indicates a higher level item.
When using this product, be sure to observe the
precautions in the Safety Information Manual. Items
specific to this product are given below.
Be careful of hearing loss.
Wear earplugs when working near the PXB series when it
is running.
The noise sound pressure level of this product is 80 dB or
less, but when this product is operated in the same place
as another product with a large noise sound pressure level
or when several of this product is operated simultaneously
in the same place, the pressure level near the product may
exceed 80 dB.
• This equipment is not intended for use in residential
environments and may not provide adequate
protection to radio reception in such environments.
• The exhaust air may become hot.
Stay away from the exhaust air flow. The air outlet of the
PXB series should be 50 cm or more away from the wall
or objects installed so that the exhaust air does not
directly hit the wall or objects installed.
• When using or storing this product, be sure to observe
the temperature and humidity ranges. For environmental
conditions, see General Specifications
(p. 180).
• The PXB series is designed with the assumption of local
regeneration. Use in an environment where the power at
the site is greater than the regenerated power.
Notations Used in This Manual
Safety Precautions
Notes on Usage
