KiloVault HLX Series User Manual

Also, set your charge controller’s Recharge / Rebulk voltage, where a new charge cycle
starts, to just above your inverter/chargers recharge setting, so the solar charge controller
starts charging before the inverter does.
Setting
Values - Volts are per battery in a single
string, Amps are per string in parallel
1200 Battery Capacity
1200 Wh, 100 Ah
1800 Battery Capacity
1800Wh, 150 Ah
3600 Battery Capacity
3600Wh, 300 Ah
Absorb Time
2 minutes or less
Absorb Voltage
14.1
Battery Temperature Compensation
Do not use an external battery temperature
sensor with these batteries. If the sensor or
compensation value is required for a charge
controller or inverter charger to work, set the
battery temperature compensation to 0mV/°C
Battery Temperature Compensation
0.00 mV/degC
Battery Type
Lithium or Custom, whichever lets you set the
recommended settings
Battery Voltage - Nominal
12 V
Bulk Termination Voltage (if applicable)
13.9 V
Bulk Voltage
14.1 V
Charge Cycle
3 stage
Equalization
Disabled
Float Voltage (set below the resting voltage of
the battery bank)
≈13.6 V or lower. Low enough to not trigger
float when the battery "relaxes" after charging
stops.
Max Float Current
10 A
Maximum Charge Rate - 1200
1.25C, 80 A
Maximum Charge Rate - 1800
1C, 150 A
Maximum Charge Rate - 3600
C/2, 150 A
KiloVault
®
LLC • 330 Codman Hill Road, Boxborough, MA 01719 • +1 (888) 218-5924 • info@kilovault.com • www.kilovault.com
13
