KiloVault HLX Series User Manual

Battery Temperature Compensation
0 mV/°C
Battery Type
Lithium or Custom, whichever lets you set the
recommended settings
Bulk Voltage
14.1 V
Charge Cycle
2 stage no float
Default Battery Temperature
Warm
Equalization
Disabled
Float Voltage
n/a
HBCO (High Battery Cut Out)
14.4 V
LBCO (Low Battery Cut Out)
12.25 V (or as close as it can be set)
LBCO Delay
5 seconds
LBCO Hysteresis
0.5 V
Max Bulk Current
Set to whatever percentage of the inverter
current plus the charge controller current is less
than or equal to 100 A
Peukert Factor
1.05
Recharge/Re-Bulk Volts (≈80% DoD)
12.75 V
1200 - Recommended Charge Current
60 A per HLX in Parallel (Solar Charge Controller
Amps + Percentage of Inv/Charger's Mac DC
Output. Ex: For an XW Pro, it would be a
percentage of 140 A, the XW Pro’s Max DC
Output Current)
1800/3600 - Recommended Charge Current
100 A per HLX in Parallel (Solar Charge
Controller Amps + Percentage of Inv/Charger's
Mac DC Output. Ex: For an XW Pro, it would be a
percentage of 140 A, the XW Pro’s Max DC
Output Current)
1200 - Standard Charge Current
60A
1800/3600 - Standard Charge Current
100 A
4.2 - Solar Charge Controller Settings
A couple of notes regarding charge controller settings. When used along with an inverter
charger, we suggest that the solar charge controller be set to 3-stage charging, while the
inverter/charger is set to 2-stage No Float. That way you’re floating your batteries for free
with the sun.
KiloVault
®
LLC • 330 Codman Hill Road, Boxborough, MA 01719 • +1 (888) 218-5924 • info@kilovault.com • www.kilovault.com
12
