Kinetec Spectra Essential - Technical Specifications; Symbols Used; Warranty

Spectra Essential EN 10/12
Technical specifications
Product:
Lifespan of the machine: 12 years
Weight: 12Kg (26 pounds)
Splint dimensions: 95cm (37 inches) x 33cm (13 inches) x 33cm (13 inches)
Angular limits: -10° to 120°
Speeds: from 45 to 155° per minute
Patient sizes: Full leg: 71 to 99 cm (28 to 39 inches)
Tibia: 38 to 53 cm (15 to 21 inches)
Femur: 33 to 46 cm (13 to 18 inches)
Maximum weight of the user: 135 kg (297 pounds)
Acoustic pressure: <70dB
Electricity:
Power supply: 100-240V~
Frequency: 50-60 Hz
Power consumption: 50 VA
Class: Device of Type BF Class II or Type B Class I
Protection classification: IP 20 (Protected against solid objects greater than 12.5mm,
but not protected against liquids)
Fuse: T 750mA 250V 6.3 x 32mm (Kinetec order: 4610007434)
Environment:
Storage/transport conditions: Temperature: -25 to 70°C / -13 to 158°F.
Relative humidity: up to 93% without condensation.
Operating conditions: Temperature: 5 to 40°C / 41 to 104°F.
Relative humidity: 15% to 93% without condensation.
Atmospheric pressure: 700 hPa to 1060 hPa.
Symbols used
Warning or CAUTION
(consult the accompanying
documentation)
Speed
Flexion limit
STOP (power off)
Pause
Extension limit
ON (power on) Increase
Start movement
Right way up when box is stored Decrease
Stop movement
Contains electric and electronic
components; do not throw away with
household refuse.
Temperature Limit during storage or
transport
~
Alternating current
Follow the instructions for use
Fragile
Keep dry during storage or transport
Follow the instructions for use
Class II device
TYPE BF device
(protection against electric shocks)
TYPE B device
(protection against
electric shocks)
Warranty
The KINETEC warranty is strictly limited to the replacement, free of charge, or to factory repairs of part(s) recognised as
defective.
KINETEC guarantees its continuous passive motion systems for 2 years against all defects of manufacture from the date
of purchase by the consumer.
KINETEC is the only organization able to assess the application of the warranty to its systems.
The warranty will be considered null and void if the device has been used abnormally or under conditions of use other
than those indicated in the user's manual.
The warranty will also be considered null and void in the event of deterioration or an accident due to negligence,
inappropriate surveillance or inappropriate maintenance, or due to transformation of the equipment or an attempt to
repair the equipment.
