King-Dome 9754 - Table of Contents

Page 1
DIRECTV
®
is a registered trademark of DIRECTV, Inc.
Dish Network
®
is an official trademark of Echostar Communications Corporation.
Bell TV is an official trademark of Bell Canada.
DVB
®
is a trademark of the DVB Digital Video Broadcast Project (1991-1996).
HDMI
TM
is a trademark of HDMI Licensing LLC.
IMPORTANT!
The satellite TV market is expanding and changing. The information in this manual was accurate at the time
of printing. If your King-Dome does not operate as outlined in this manual please call King Controls at (952)
922-6889 or visit our website at www.kingcontrols.com.
This King-Dome is factory pre-set for DIRECTV
®
standard digital programming broadcast from the
101° W satellite. If you also receive your local channels from DIRECTV’s 119 satellite or if you subscribe to
Dish Network
®
or Bell TV programming, you must re-configure the antenna to work with your satellite service.
Doing this will allow the King-Dome to lock on the correct satellites to receive your programming and
also enable automatic satellite switching via the receiver’s remote control for multi-satellite service.
Antenna configuration is a one time procedure that MUST BE COMPLETED
before using your King-Dome
antenna. Configuration may be done with the supplied wall mount controller or the #1844 Keypad
(dealer tool). See the antenna configuration section in this manual for specific instructions.
The King-Dome can receive available HDTV programming from DIRECTV Ku band satellites at 101° and 119°.
It will not receive channels broadcast from DIRECTV’s Ka band satellites at 99° and 103°.
Please read this entire manual before beginning the installation.
TABLE OF CONTENTS
Section Contents Page
1. INTRODUCTION............................................................................................................2
2. DEFINITION OF TERMS...............................................................................................3
3. INSTALLATION.........................................................................................................4-12
4. ANTENNA CONFIGURATION................................................................................13-29
5. OPERATION...........................................................................................................30-33
6. TROUBLESHOOTING.................................................................................................34
7. MAINTENANCE...........................................................................................................35
8. LIMITED WARRANTY .................................................................................................36
