Page 2
The King-Dome Automatic Satellite System includes 2 main components (Fig. 1).
Dome (Antenna) Unit Located on the roof of the vehicle. The antenna is covered by a
protective dome that keeps operational components free from the
elements.
Controller Located in the vehicle. Activates the search mode and provides
limited diagnostic functions using the status light.
SECTION 1
INTRODUCTION
Note: A TV, satellite receiver, and program subscription are also required for satellite TV viewing (sold separately
).
Fig. 1
Note: Overview only.
See Installation Section for specific
wiring diagrams.
