King gates Modus 280 - Use limitations; Installation preparation works

15
EN
3.3 - Use limitations
Beforeinstallingtheproduct,checkthatthesizeandtheweightof
thegateleafarewithinthelimitsstatedinchart 1.
kg - Maximum gate leaf weight
mm - maximum gate leaf length
WARNING!
- The single leaf must not exceed 4.2m in length.
Chart 1 - Use limitations
100
200
300
400
500
500 1000 2000 35003000 40002500 45001500
(mm)
(kg)
3.4 - Installation preparation works
Fig.2 shows an example of an automation system using King-
Gatescomponents.Thesecomponentsarepositionedfollowinga
typicalandstandardsetup.
WithreferencetoFig.2,establishtheapproximatepositionwhere
eachcomponentwillbeinstalledandthenarrangeanyconduits
fortheelectricalwiring.
Useful components for a complete system:
1-MODUSMASTERgearmotor
2-Pairofphotocells
3-Pairofstops(openposition)
4-Photocellcolumns
5-Flashingwarningdevicewithbuilt-inantenna
6-Keyselectorordigitalkeypad
7-Verticalsolenoidlatch
8-MODUSSLAVEgearmotor
3
6
4
4
3
5
7
8
2
2
1
Fig. 2
