KING 2016E - Page 18

18
1
2
3
4
6
5
7
5
4
1
3
2
Repair Parts
Key Part No. Description Qty.
1 89066 Firebrick (4-1/2 X 9) 15
2 40487 Plug, Ash 1
3 24103 Firebrick, Half (4-1/2 X 4-1/2) 2
4 86645 Tube (Ø7/32), Secondary Air 1
5 88250 Board, Ceramic Fiber 2
In order to maintain warranty, components must be replaced using original manufacturers parts
purchased through your dealer or directly from the appliance manufacturer. Use of third party
components will void the warranty.
