KING 2016E - Repair Parts

17
Repair Parts
Key Part No. Description Qty.
1 69427 Ash Pan 1
2 40292 Flue Collar 1
3 69354 Blower Assembly (B36) 1
4 25300 Blower Housing 1
5 25305 Deector, Air 1
1
5
2
3
4
In order to maintain warranty, components must be replaced using original manufacturers parts
purchased through your dealer or directly from the appliance manufacturer. Use of third party
components will void the warranty.
1
2
3
4
6
5
7
5
4
1
3
2
Key Part No. Description Qty.
1 891084 Handle Rod 1
2 891112 Feed Door 1
3 891108 Glass w/King Logo 1
4 88087 Door Glass Gasket 1
5 891114 Top/Side Window Bracket 4
6 891115 Bottom Window Bracket 1
7 891113 Feed Door Gasket 1
